Request For Our Latest Prices On Monel Nuts in Delhi, India!
Monel nuts are available at Punit Fasteners that are made up of high-quality material and are suitable for use in harsh environments. Monel nuts are produced from nickel-copper alloy and are well known for their features such as high strength, corrosion resistance, and durability. These nuts can be used in marine, chemical processing and aerospace industries because they offer high performance and stability in such conditions.
Punit Fasteners is a reputable Monel Nut manufacturer and supplier that offers customers in Delhi and throughout India corrosion-resistant fastening solutions. Monel nuts are perfect for high-temperature, chemical, and marine applications because of their remarkable strength and resilience to adverse conditions. These nuts are made to meet international quality and performance standards using premium Monel alloys, like Monel 400 or K500. Punit Fasteners guarantees dependable and long-lasting fasteners made to endure harsh operating conditions in the most exacting industrial sectors thanks to its precise engineering, strict tolerances, and availability in a range of sizes and specifications.
|
Element |
Content (%) |
|
Nickel, Ni |
63.00 min |
|
Silicon, Si |
0.5 max |
|
Carbon, C |
0.3 max |
|
Sulphur, S |
0.024 |
|
Copper, Cu |
28-34 |
|
Iron, Fe |
2.5 max |
|
Manganese, Mn |
2 max |
|
Properties |
Metric |
Imperial |
|
Tensile strength(annealed) |
517-620 MPa |
75-90 ksi |
|
Yield strength |
172-345 MPa |
25-50 ksi |
|
Modulus of elasticity |
179 GPa |
26000 ksi |
|
Poisson’s ratio |
0.32 |
0.32 |
|
Material |
Specification |
Standards |
Size |
Length |
|
Monel Nuts
|
IS
BS
ASTM
|
ASTM F467 |
3 mm to 200 mm
|
M02 to M33
|
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Monel 400 or Monel K500, nickel-copper alloys with roughly 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, and silicon, are commonly used to make Monel Nuts. While K500 is precipitation-hardened for greater strength and hardness, Monel 400 offers excellent corrosion resistance and moderate strength. Tensile strength of 480–960 MPa, yield strength of 170–690 MPa, and elongation of up to 35% are typical mechanical characteristics. These nuts withstand corrosion from seawater, acids, and alkalis while retaining their structural integrity in the face of extreme temperatures.
Applications requiring high durability and corrosion resistance frequently use monel nuts. Oil and gas, power generation, chemical processing, marine engineering, and aerospace are examples of common industries. These nuts are perfect for securing parts in seawater piping systems, offshore rigs, pumps, heat exchangers, and valves. They are appropriate for applications involving brine, sulphuric acid, and hydrofluoric acid due to their exceptional resistance to acidic and alkaline environments. Additionally, monel nuts function remarkably well under high temperatures and pressures. To address particular operational and environmental challenges, Punit Fasteners provides Monel Nuts in both standard and customised specifications.
