Home > Stainless Steel Threaded Rod
Request For Our Latest Prices On Stainless Steel Threaded Rod in Delhi, India!
Punit Fasteners is a leading manufacturer and supplier of stainless steel threaded rods in Delhi, India. We offer high-precision rods for structural and mechanical uses. Our threaded rods are made from top-quality stainless steel grades like 304 and 316, ensuring strong performance, corrosion resistance, and dimensional consistency. These rods work well for tensioning applications and long fastening needs where bolted connections must be customized or extended. Punit Fasteners provides rods in various lengths, diameters, and threading types to meet the needs of construction, electrical, plumbing, and heavy engineering sectors with reliable fastening solutions.
Stainless steel threaded rods are usually produced using 304 or 316-grade stainless steel. They contain 18-20% chromium and 8-10.5% nickel, with 316 also containing molybdenum for better chloride resistance. These rods have tensile strengths from 500 to 860 MPa and show high resistance to corrosion, oxidation, and chemical exposure. They maintain their shape under load and thermal stress, providing excellent mechanical strength, hardness, and ductility. The threads are rolled or cut to precise tolerances, ensuring smooth engagement with nuts and couplings in structural and mechanical assemblies.
| Specifications | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of Stainless Steel Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard SS Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 SS Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated Stainless Steel Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | Stainless steel : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Stainless Steel, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Stainless Steel Threaded Rod | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless steel threaded rods are applied in construction frameworks, bridge supports, HVAC systems, electrical conduit mounting, chemical plant equipment, and marine settings. They excel in situations requiring long fastening lengths or adjustable tensioning, such as in concrete reinforcement, pipeline supports, and anchoring systems. Their resistance to corrosion makes them suitable for wet, acidic, and marine environments. In electrical systems, they act as grounding rods or bus bar supports. Threaded rods are also common in industrial machinery and equipment installation. Their flexibility, combined with strength and rust resistance, ensures secure, lasting connections in various industries.
At Punit Fasteners, we ensure that our Stainless Steel Threaded Rods are installed with the utmost care to maintain their integrity integrity and quality while in transit. Each rod is individually wrapped in protective material to prevent wear and tear. They are then safely packed in sturdy weatherproof boxes or wooden crates designed to withstand rough sea shipping. We also offer bespoke packaging solutions to meet customers’ specific needs, ensuring safe and efficient deliveries every time.
